Impro heavy duty orbital motors

The Impro Fluidtek Heavy Duty orbital motors have been specially developed for demanding applications. With their robust construction and advanced technologies, they offer reliable performance under extreme conditions. These motors are ideal for heavy industrial applications such as construction machinery, agricultural equipment and material handling. The improved fluid technology ensures efficient performance and a long service life of the motors. Learn more about the wide range of Impro Heavy orbital motors.

________________________________________________________________________________________________________________________________________________________________________________________________________________________

Light Duty Motors

Power (int.) up to approx. 18 kW
________________________________________________________________________________________________________________________________________________________________________________________________

WD Series

The WD motor series is an economical solution for light applications requiring high torque. It has a small design and yet offers high efficiency over a wide power range. The integrated check valves and the leakage oil connection reduce the pressure on the internal seals and thus increase the service life of the product. The motor series is suitable for industrial and mobile applications such as car wash brushes, food processing equipment, conveyor belts, machine tools, agricultural equipment, sweepers, skid steer loader attachments and much more.

Technical data:

• Displacement: 25-400 cm³/rev
• Max. Pressure (peak): 225 bar
• Max. Speed (cont.):  1,361 rpm
• Max. Flow rate (cont.): 60 l/min
• Max. Torque (cont.): 480 Nm
• Temperature range: -30°C - 85°C
• Optimum viscosity: 20 - 43 cSt
• Filtration: min. ISO 17-14
• *the exact values depend on the motor size and design

Function and advantages:

• Built-in check valves provide versatility and extended seal life
• A variety of flange and shaft options provide application design flexibility
• Spool valve design provides superior performance and smooth operation over a wide speed and torque range
• Integrated rotor design provides smooth performance, compact volume and light weight
• Low port option is suitable for applications with limited space
• Optional sensors

Typical applications and examples:

• Agricultural equipment
• Sweepers
• Grain screw conveyors
• Conveyors
• Brush drives
• Food processing
• Spreaders
• Screw conveyors
• and many more

_________________________________________________________________________________________________________________________________________________________________________________________________________

WG Series

With the WG Series, Impro Fluidtek continues its tradition of delivering motors that stand the test of time in demanding applications. The WG motors provide an exceptionally solid platform for any light duty application where side load can be an issue. The WG motors feature our unique design that reduces friction and extends the life of the motor. With a displacement of 41 - 404 cc per revolution and a choice of mounting, shaft and connection options, this motor is suitable for a wide range of applications. The WG is the perfect solution when you need improved performance and long motor life at an affordable price.

• Displacement: 40-400 cm³/rev
• Max. System pressure (peak): 207 bar
• Max. Speed (continuous): 830 rpm
• Max. Flow rate (continued): 57 l/min
• Max. Torque (cont.): 548 Nm
• Temperature range: -30°C - 85°C
• Optimum viscosity: 20 - 43 cSt
• Filtration: min. ISO 17-14
• Values vary depending on the type and size of the motor

Features and benefits:

• The needle bearing is optimally positioned to place the load as close as possible to the centerline of the bearing.
• High pressure Buna® shaft seal provides superior seal life and performance and eliminates the need for housing draining
• Heavy duty drive connection receives full flow lubrication for long life
• Rotor design increases efficiency and life by using roller contacts as opposed to solid sliding contact designs
• Rubber coated steel face seal will not extrude or melt under high pressure or temperature
• Optional sensors

Typical applications:

• Conveyor systems
• Light wheel drives
• Grain augers
• Feed rollers
• Brush drives
• Interlocking systems
• Sweepers
• Spreaders
• Auger drives
• And more

________________________________________________________________________________________________________________________________________________________________________________________________________________________

WP Series

The WP motor series is an economical alternative to a more complex roller gearbox design while still offering high efficiency over a wide power range. Designed for lightweight applications requiring high torque in a compact package, these motors are suitable for industrial and mobile applications such as car wash brushes, food processing equipment, conveyors, machine tools, agricultural equipment, sweepers, skid steer loader attachments and more.

• Displacement: 25-400 cm³/rev
• Max. System pressure (peak): 240 bar
• Max. Speed (continuous): 1,570 rpm
• Max. Flow rate (continued): 60 l/min
• Max. Torque (cont.): 488 Nm
• Temperature range: -30°C - 85°C
• Optimum viscosity: 20 - 43 cSt
• Filtration: min. ISO 17-14
• Values vary depending on the type and size of the motor

Features and benefits:

• Built-in check valves provide versatility and extended seal lifeA variety of brackets and shafts provide flexibility in application design
• Spool valve design provides superior performance and smooth operation over a wide range of speeds and torques
• Standard high-pressure shaft seals provide superior life and performance
• Optional sensors

Typical applications:

• Agricultural equipment
• Car washes
• Food processing
• Spreaders
• Augers
• Conveyors
• Sweepers
• Grain augers
• Feed rollers
• Brush drives
• And more

________________________________________________________________________________________________________________________________________________________________________________________________________________________

WR Series

WR Series motors incorporate the latest developments for smooth performance, efficiency and durability. The optimized rotor geometry with seven precision rollers eliminates sliding friction and ensures rolling contact between the rotor and stator, which increases the efficiency of the motor. A three-zone control valve, integrated check valves and a housing drain device reduce pressure on the internal seals and increase the service life of the product. A wide range of mounting, shaft, motor displacement and connection options are available to meet all application requirements.

• Displacement: 40-400 cm³/rev
• Max. System pressure (peak): 241 bar
• Max. Speed (continuous): 1,116 rpm
• Max. Flow rate (continued): 61 l/min
• Max. Torque (cont.): 551 Nm
• Temperature range: -30°C - 85°C
• Optimum viscosity: 20 - 43 cSt
• Filtration: min. ISO 17-14
• Values vary depending on the type and size of the motor

Features and benefits:

• A variety of brackets and shafts provide flexibility in application design
• A high pressure shaft seal provides superior seal life and performance
• The spool valve design ensures excellent performance and smooth operation over a wide speed and torque range
• Built-in check valves in the housing provide versatility and increase seal life
• Optimized rotor geometry ensures smooth running of the highly efficient product
• Optional sensors

Typical applications:

• Agricultural equipment
• Sweepers
• Grain augers
• Feed rollers
• Brush drives
• Conveyor systems
• Food processing
• Spreaders
• Augers
• And more

______________________________________________________________________________________________________________________________________________________
Medium duty motors

Power ratings (int.) up to approx. 22 kW
______________________________________________________________________________________________________________________________________________________

CE-Series

The combination of compact size, low weight and low efficiency makes the CE motor the best wheel drive motor available. To reduce the overall length and weight of the motor, all unnecessary material has been removed from the housing and the valve has been fitted to the front of the rotor. The pressure compensated balancer plate allows the motor to maintain a high volumetric efficiency at start-up and a high mechanical efficiency during operation. All of these features make CE Series motors 10-25% lighter and more compact than the competition, making them perfect for applications with strict weight and size requirements.

• Displacement: 120-750 cm³/rev
• Max. System pressure (peak): 241 bar
• Max. Speed (continuous): 360 rpm
• Max. Flow rate (continued): 76 l/min
• Max. Torque (cont.): 1,082 Nm
• Temperature range: -30°C - 85°C
• Optimum viscosity: 20 - 43 cSt
• Filtration: min. ISO 17-14
• Values vary depending on the type and size of the motor

Features and benefits:

• The needle bearing is optimally positioned to allow the load to be placed as close as possible to the centerline of the bearing
• Three bearing options allow the load carrying capacity of the motor to be matched to the application
• The valve in the motor provides cost-effective and efficient oil distribution and reduces the overall length of the motor
• Pressure compensated balancer plate improves volumetric efficiency at low flow and high pressure

Typical applications:

• Medium-duty wheel drives
• Feed rollers
• Gripper heads
• Broom drives
• And more

________________________________________________________________________________________________________________________________________________________________________________________________________________________

RE-Series

RE-Series motors offer the perfect compromise between price and performance, providing high work output at a reasonable price. Although these motors perform well in a wide range of applications, they are particularly suitable for low flow, high pressure applications. During start-up, the pressure causes the balancer plate to flex towards the rotor, which significantly improves volumetric efficiency. When the motor reaches operating pressure, the balancer plate relaxes, allowing the rotor to rotate freely, resulting in higher mechanical efficiencies. This power is transmitted to the output shaft via the most durable drive link in its class. Four bearing options in combination with standard mounting flanges and output shafts allow the motor to be configured for almost any application.

• Displacement: 120-750 cm³/rev
• Max. System pressure (peak): 276 bar
• Max. Speed (continuous): 360 rpm
• Max. Flow rate (continued): 83 l/min
• Max. Torque (cont.): 1,096 Nm
• Temperature range: -30°C - 85°C
• Optimum viscosity: 20 - 43 cSt
• Filtration: min. ISO 17-14
• Values vary depending on the type and size of the motor

Features and benefits:

• High pressure shaft seal provides superior seal life and performance and eliminates the need for case draining
• Three bearing options allow motor load capacity to be matched to application
• Heavy duty drive member is the most durable in its class and receives full flow lubrication for long life
• Valve in motor provides cost-effective and efficient oil distribution and reduces overall motor length
• Pressure compensated balancer plate improves volumetric efficiency at low flow and high pressure
• Optional sensors

Typical applications:

• Medium-duty wheel drives
• Mixers
• Swivel drives
• Feed rollers
• Augers
• Winch drives
• Gripper heads
• Broom drives
• And more

_________________________________________________________________________________________________________________________________________________________________________________________________________
